Plastic diabolo roller 70 mm - 100 kg
Show all:
Cable pulleys,Tube wheels
Description
Plastic diabolo weight 70 mm - 100 kg
Polyamide diabolo roller (PA6) with double ball bearings.
Designed to roll on a tube with a diameter of Ø 51 mm.
Discount for orders of 40 or more, see scaled prices or contact us for a quote.
Read more
Specifications
- Article number: 178.800
- Wheel diameter: 70 mm
- Wheel width: 59 mm
- Shaft diameter: 10 mm
- Ash: undefined
- Hub length: 58 mm
- Hub diameter: undefined
- Groove radius: undefined
- Groove depth: undefined
- Groove width: undefined
- Carrying capacity: 100 kg
- Type of wheel: undefined
- Material: Polyamide (plastic)
- Groove type: undefined
- Bearing type: 6000-2Z
- Temperature: - 20 / + 80 °C
Show all
Specifications
- Article number: 178.800
- Wheel diameter: 70 mm
- Wheel width: 59 mm
- Shaft diameter: 10 mm
- Ash: undefined
- Hub length: 58 mm
- Hub diameter: undefined
- Groove radius: undefined
- Groove depth: undefined
- Groove width: undefined
- Carrying capacity: 100 kg
- Type of wheel: undefined
- Material: Polyamide (plastic)
- Groove type: undefined
- Bearing type: 6000-2Z
- Temperature: - 20 / + 80 °C
